Forming capacity
Forming area: 19 x 17 in
Sheet size: 20 x 18 in
Max depth of draw: 11.4 in
Max material thickness: 0.2 in
Power
Single phase power requirements: 208-240V / 20A
Power consumption (kW): 4.2
Heating
Heater type: Quartz
Heating zones: 4
Air
Air requirements (PSI/bar): 87 / 6
Operating interface: 3.8" Mono HMI
Vacuum pump type: Dry rotary vane pump
Pump flow (SCFM @ 0 in. / 60Hz): 7.1
Pump flow m3 /h @ 0mbar / 50Hz: 10.0
Mould release method: External air supply
Dimensions
Machine width: 29.8 in
Machine height: 44.9 in
Machine depth: 58 in
Machine weight: 275.6 lbs
