Forming Area (mm/inches): 482 x 432 / 19 x 17
Sheet Size (mm/inches): 508 x 457 / 20 x 18
Max Depth of Draw / Max Tool Height (mm/inches): 185 / 7.3
Max Material Thickness (mm/inches): 6 / 0.25
Heater Type: Quartz
Heating Zones: 4
Width (mm/inches): 720 / 28.4
Height (mm/inches): 538 / 21.2
Depth (mm/inches): 1394 / 54.9
Weight (kg/lbs): 100 / 220.0
Single Phase Power Requirements: 208-240V / 13A
Power Consumption: 3.2kW
Operating interface: 3.8" Mono HMI
Vacuum Pump Type: Diaghram
Pump Flow (SCFM @ 0 in. / 60Hz) (Pump flow m3 /h @ 0mbar / 50Hz): 3.0 (4.9)
Mould Release Method: Pump exhaust
