New Formech Formech 300DT Vacuum Former (120v version)

Description

The brand new 300DT is Formech's smallest desktop machine to date. Keeping the functionality of its predecessor, the Compac Mini, the 300DT is smaller in volume and lighter than ever. Compared with other compact machines on the market, the 300DT comes with a quiet built in vacuum pump and moulding release. Easy to transport, move, and use, this 300DT is the perfect solution for creative hobbyists, artisans, and students.
Technical Specifications
Forming Area (mm / inches): 280 x 230mm /11 x 9”
Sheet Size (mm / inches): 300 x 250mm /12 x 10”
Max Depth of Draw: 136mm / 5.3''
Max Material Thickness: 4mm / 0.15''
Heater Type: Quartz
Heating Zones: 1
Width: 454mm / 17.9”
Height: 355mm / 14”
Depth: 742mm / 29.2''
Weight: 29kg /64lbs
Single Phase Power Requirements: 208-240V / 13A
Other Voltage (USA): 110-120V / 13A
Power Consumption: 1.1kW (1.2kW USA)
Vacuum Pump Type: Diaphragm
Pump Flow (m3 /h @ 0mbar / 50Hz) Pump Flow (SCFM @ 0 in. / 60Hz): 2.4 / 1.7
Mould release method: Pump exhaust
Air Requirements: n/a
