New Shear-Line SL120 Roller Die-Cutter 120”

Description

New Shearline SL120 Roller Die Cutter 120”

Model: SL120

Maximum Cutting Width: 112” (2844 mm)

Inch: 120”

mm: 3050 mm

Control:

Each machine is fitted with latest Mitsubishi Inverter Drive technology which incorporates soft start ramp up and ramp down, soft stop. The Mitsubishi touch screen HMI gives the operator full control over speed and automatic return, plus a range of other facilities.

Shearline features:

 Reduced the sleeve change process to under 20 minutes.
 Upgraded system controls.
 New Mitsubishi touch screen color HMI now includes safety circuit diagnostics, batch counting and many production control aids.
 New food and medical Shear-line’s in stainless steel.
 Redesigned heavier duty press section, but with easy maintenance strip-down.

Unique Sleeve Change Solution:

The Shear-line is up to 50% faster than similar flatbed Die-Cutting presses. Through the use of our cleverly designed Cutting Anvil Sleeve facility, the Shear-line is safer, easier and quicker to operate. The Cutting Anvil sleeves can be changed in under 20 minutes by only one operator without the need for heavy lifting equipment.

General:

Guaranty Warranty is 3 years parts only, excluding consumables.
Optional extras Powered extension tables Servo powered press section (Automatic set up)
Consumables Polypropylene Sleeve (Lasting between 8-12 months depending on usage) Friction wheels

Safety:

The Shear-line is one of the safest roller press die-cutter machines on the market place. All doors and safety guards are installed with safety interlocks that instantly cut the machine when broken. Integrated safety software and control password.

Technical Data
Length (Without Extension Tables): 118” (3000mm)
Height: 54” (1375mm)
Width: 145'' (3680mm)
Electrical Specifications: 3 phase
Main Drive Motor: 2.2Kw
Power Consumption: Peak 22 amps / Cont; 12 amps
Roller Speed: 50 rpm
Diameter of main press rolls: 8” (216mm with anvil sleeve)

Upgrades:
Sleeve change from 15 stages down to 7. Quicker, easier and a more simplified task.
Upgraded touch screen and software with new job timer, batch count, safety and monitoring features.
Two handed safety start feature, this can also be disabled through the HMI - password protected.
New press section height measuring system. This allows you to measure the press section position. This is great for quick set up and die change over. Set and customized through an added display.
Voltage panel meter, an added safety feature.
New magnetic switches and interlock door hinges.
Better maintenance access.
